LPG Reducer SHARK 1500

High-quality single-stage reducer supporting engines up to 200 HP.

Buy online Product Data Sheet Files to download

SHARK 1500 is a high-quality single-stage gas pressure reducer dedicated to LPG installations in engines with a power of up to 147 KW/200 HP. It reduces the pressure and evaporates the gas that powers the engine. It maintains the fuel pressure at the appropriate level, which ensures optimal operating conditions of the entire system.

SHARK 1500 has an innovative design that guarantees proper operation in difficult climatic conditions, which translates into trouble-free operation of the gas installation. The original membrane structure ensures maximum efficiency and no pressure drops in the full load range.

When designing this reducer, we took into account the possibility of mounting in two planes, which in many cases is a great help for the installer.

Integrated electrovalve and liquid phase gas filter.

SHARK is equipped with a liquid phase gas filter and an increased flow solenoid valve. We were the first in Poland to use a valve with a diameter of 8 mm. Thanks to it, there are no restrictions in the gas flow. And they are strongly felt under heavy loads, if standard solutions are used.

The main advantages

Supported power: <200 HP
Output pressure: 1.5 bar
Integrated solenoid valve and liquid phase gas filter
8 mm diameter valve
Possibility of mounting in 2 planes

Specification

Integrated shut off electrovalve with voltage supply:	12 V
Integrated gas filter	liquid phase
Output pressure	1,5 bar
Pressure adjustment range	1,3 ÷ 1,9 bar
Engine power	<200 HP
Pressure regulation	SW4
Gas inlet port diameter	Ø8 mm
Gas outlet port diameter	Ø12 mm
Rotary water pipe elbows diameter	Ø16 mm
Vacuum input	Ø5 mm
Dimensions	95 x 109 x 93 mm
Weight	1,6 kg
